Workshop Press: 150-200 Ton High Tonnage H Frame Presses

Power Team Shop Presses 150 200 Tonne

PJM Industrial are proud to be distributors of the SPX Power Team range of Workshop Presses & other products and can source any of the Power Team products.

150-200 Ton High Tonnage H Frame Press Features

This giant high tonnage workshop press, standing 7 1/2 feet or 2.3 metres tall, can handle the really big jobs.

It may be used horizontally for special pressing applications with user-supplied supports.
The workhead has wide horizontal travel; the rugged press frame withstands load of rated capacity across the full width of the frame.
The winch mechanism provides easy positioning of the press bed & locks in place for insertion of retaining pins. The upper bolster can be lowered 11″ (279 mm) for convenient positioning for repetitive jobs.
The uprights are placed for easy side entry of bars or shafts for straightening or bending.
Fast cylinder approach is provided by the PQ1204S ‘quiet’ electric / hydraulic pump. It has a remote control hand switch, enabling the operator to view work from all sides with fingertip control of cylinder piston travel.

150-200 Ton High Tonnage H Frame Press Accessories

The SPX Power Team 150-200 High Tonnage H Frame workshop press accessories that are available include:

Workshop Press Accessory Kit (135 KB)
Rubber Tire Removing/Installing Set (86 KB)
Threaded Adapters (86 KB)
“V” Blocks (86 KB)

Simply click on a link above for a PDF with more information about the specific accessory.

150 – 200 Ton H Frame Press Technical Data

Order Number	Capacity (tons)	Type of Cylinder Used	Stroke (mm)	Cylinder Model	Speed-Advance (mm./min.) †	Speed-Pressing (mm./min.) †	Type Pump	Valve Pump	Pump Model ††	Weight (kg)
SPE15013DS	150	Double-Acting	333	RD15013	610	99	Electric	4-Way	PQ1204S	769
SPE10010	200	Double-Acting	333	RD15013	457	74	Electric	4-Way	PQ1204S	813

† Typical performance based on 100 psi and 10,000 psi pump specifications. Actual speeds may vary under operating conditions.
†† Pump standard with press. Other Power Team pumps can be substituted. dBA at idle and 10,000 psi: 73/78, measured at 3 foot distance, all sides.
* Pre-wired at factory for 460V.
** Solenoid valve with 24 volt remote control hand switch.

150-200 Ton H Frame Workshop Press Documents

For more information select from the following Product PDFs:

More Information?

If you require more information or have any questions regarding the 150-200 T H Frame Workshop Press from SPX Power Team, please feel free to call us on (+61 3) 9553 4882 or 0412 720 638, send us an email at peter@pjmindustrial.com.au or use our Contact Form to submit an inquiry.
